APPLICATIONS
- For sewing light to heavy-weight materials such as leather, vinyl, upholstery, synthetics, canvas, vinyl and various coated and laminated products
- Designed for stitching such products as auto, boat and furniture upholstery, tarpaulins, covers, sails, tents, camping trailer covers, awnings, umbrellas, tops, bags, luggage, handbags, travel-ware accessories, sports and camping equipment, wearing apparel, outdoor clothing, canvas shoes, slippers, orthopedic appliances, etc.
- Suitable for double needle seaming, binding, taping and piping operations
FEATURES
- Two needle mechanism readily makes two parallel lines of stitches
- Compound feed, walking foot mechanism insures even feeding of material
- Large hooks and bobbins assures longer operation between bobbin changes
- Centra-Lube® semi-automatic lubrication system
- Automatic hook lubrication
- Oil fed take-up
- Simple adjustment permits raising and lowering of the center foot which allows for sewing different thicknesses of material
- Safety clutch protects the hooks from being damaged
- Various needle gauges available
- Synchronized puller available (add suffix -P)
- Large Hooks and bobbins and reverse feed/long stitch - 2 1/2 s.p.i.
ADDITIONAL INFORMATION
SPECIFICATIONS
| Number of Needles | 2 (Double) |
| Feeding Mechanism | Walking Foot |
| Workspace | Standard Workspace |
| Standard or Full Function | Standard Functions |
| Speed, Max (S.P.M.) | 3000 |
| Clearance Under Presser Foot | 9/16" (14mm) |
| Stitch Length | 2 1/2" s.p.i. (10mm) |
| Hook Size | Large |
| Work Space | 10" (258mm) |
| Needle | 135 x 17 |
| Bobbin | Metal 15041 Pre-wound S or U |
| Bed Size | 7" 20 3/8" (177mm x 518mm) |
| Stitch Type | 301 |
| Gross Weight | 97 lbs. (44 kgs.) |
| Needle Bar Stroke | 1 5/16" (33mm) |
| Available Needle Spacing | 1/8" (3.2mm) - 1 1/2" (38.1mm) |
| Standard Needle Spacing | 1/4" (6.4mm) |
| Hook | 15502 |
